AISI 1020 Steel
1020 Steel is a carbon steel that is part of the American ASTM standard and is one of the common types of low carbon steel. Its chemical composition includes carbon (C) ranging from 0.18 percent to 0.23 percent , manganese (Mn) ranging from 0.30 percent to 0.60 percent , phosphorus (P) with a maximum of 0.040 percent , and sulfur (S) with a maximum of 0.050 percent .
Opis
1020 Steel is a carbon steel that is part of the American ASTM standard and is one of the common types of low carbon steel. Its chemical composition includes carbon (C) ranging from 0.18 percent to 0.23 percent , manganese (Mn) ranging from 0.30 percent to 0.60 percent , phosphorus (P) with a maximum of 0.040 percent , and sulfur (S) with a maximum of 0.050 percent .
It has a tensile strength of 410 MPa, a yield strength of 245 MPa, and a fracture elongation of 25 percent . 1020 Steel offers good machinability, weldability, and toughness. It can be used in the manufacturing of machine parts, cutting tools, bearings, gears, chains, bicycle frames, and more.
1020 Steel can be found in different states such as cold rolled, hot rolled, heat treated, and forged. The cold rolled state is suitable for parts requiring high precision and smoothness, while the hot rolled state is used for structural components requiring more deformation. Heat treating 1020 Steel can increase its hardness and strength. Forging can enhance the density and plasticity of the material.
The advantages of 1020 Steel include its wide range of applications, good machinability, and toughness. Its disadvantages are the relatively low hardness and poor corrosion resistance. The most common forms of 1020 Steel include sheets, tubes, rods, and strips.
Different countries use different grade equivalents for 1020 Steel. For example, the equivalent grade in China is 20 Steel, in Japan it is S20C, and in Germany it is C22E, all referring to the same material.
In conclusion, 1020 Steel is a commonly used low carbon steel with various applications in different industries. Its chemical composition determines its physical properties, and in combination with different forms and states, it can be used to manufacture a wide range of products.
|
|
|
|
|
|
|
|
C25,1.0406,C30,1.0528,C35,1.1181,1.0511,C45,1.1191,1.0503,C50,1.1206,1.054,C55, 1.1203,C60,1.1221,1.0601,C10E ,1.1121,C10R ,1.1207,C15E ,1.1141 C15R ,1.114,C16E .1.1148, C16R, 1.1208, C10E, S10C steel, 1010,08 steel, 1008, S15C 1015, S20C, 1020,20 Steel, S35C, 1035, S45C, C45,1045, S50C, et al |
|
|
|
|
|
|
|
|
7-15 days or according to the order quantity or negotiation |
|
|
|
|
|
|
|
|
- Our company has a professional technical service team, which can customize 1020 Steel for customers. We will continue to carry out research and development and innovation, establish an effective information exchange mechanism, continuously improve our products, and provide customers with reliable and satisfactory services.
- Our factory has state-of-the-art equipment for the production of high-quality Carbon Steel products.
